1.  Product Description:

This series of machines are designed for packing free flowing granular and blocky materials into open mouth bags. Representative Materials are Rice, Seed, Urea, Compound Fertilizer, Granulated Sugar, Rubber Granule, Feed, Fertilizer, Granulated PVC, Active Carbon, Construction Materials, Refractory Material, and etc.

2.  Technical Parameters:

l  Weighing Range: 10-50kg

l  Packing Rate: 4-20bags/min (Packing speed depends on the material features and packing bags)

l  Weighing Accuracy: ±0.2％

l  Applicable Voltage: AC220V-440V 50/60HZ Three-Phase Four-Wire (Client shall provide local voltage class and frequency)

l  Air Source Requirement: 0.4-0.8MPa Dry Compressed Air, Total Air Consumption: 0.5m3/min

l  Applicable Environment: Altitude≤2000meters, Humidity≤95% RH Non-congealable Dew, Operating Temperature: 0℃～50℃, Storage Temperature : -20℃～70℃

3.  Working Principle:

Materials flow freely due to gravity and enter into weighing system uniformly from silo to feeding unit. Machine starts and the valve of feeding unit opens, then materials will be filled into bag or weighing hopper. When weight value reaches the preset value, the feeding unit valve closes. Operator takes finished bag away or put it on belt conveyor of sewing machine. The single packing is finished.

     4.  Specification and Model:
